Reference. 1187MDD004
Dosyproof liquid dispenser for bottles, 5-50ml
Dosyproof liquid dispenser for bottle, 5-50ml
Personal advice
Description
Dosyproof liquid dispenser with a volume range of 5-50 ml.
Features:
- Ergonomic design with smooth piston movement for effortless dispensing.
- The discharge tube rotates 360º allowing dispensing into various containers.
- Double graduated scale for precise volume adjustment and clear visibility.
- Versatile telescopic feed tube compatible with bottles of different heights, from 170 mm to 300 mm.
- Easy recalibration with the supplied calibration tool.
Autoclavable at 120 ºC, 1.05 bar (15 psi) for 20 minutes.
The following limits should be considered when dispensing liquids:
- Instrument and liquid temperature from 15 to 40 ºC.
- Vapor pressure up to 500 mbar.
- Density up to 2.2 g/cm³.
- Kinematic viscosity up to 500 mm²/sec.
Certificates: the inaccuracy and imprecision values comply with standard EN ISO 8655-5.
Technical specifications:
- Volume range: 5-50 ml.
- Division: 1 ml.
- Inaccuracy %: ± 0.5%.
- Inaccuracy ml: ± 0.025 ml.
- Imprecision %: ± 0.2%.
- Imprecision ml: ± 0.1 ml.
Includes 28/38/40 and 45 mm thread adapters.
Features:
- Ergonomic design with smooth piston movement for effortless dispensing.
- The discharge tube rotates 360º allowing dispensing into various containers.
- Double graduated scale for precise volume adjustment and clear visibility.
- Versatile telescopic feed tube compatible with bottles of different heights, from 170 mm to 300 mm.
- Easy recalibration with the supplied calibration tool.
Autoclavable at 120 ºC, 1.05 bar (15 psi) for 20 minutes.
The following limits should be considered when dispensing liquids:
- Instrument and liquid temperature from 15 to 40 ºC.
- Vapor pressure up to 500 mbar.
- Density up to 2.2 g/cm³.
- Kinematic viscosity up to 500 mm²/sec.
Certificates: the inaccuracy and imprecision values comply with standard EN ISO 8655-5.
Technical specifications:
- Volume range: 5-50 ml.
- Division: 1 ml.
- Inaccuracy %: ± 0.5%.
- Inaccuracy ml: ± 0.025 ml.
- Imprecision %: ± 0.2%.
- Imprecision ml: ± 0.1 ml.
Includes 28/38/40 and 45 mm thread adapters.
